AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-36
Power Measurements Test
This test performs the following functions:
● Exercises the power meter.
● Checks the power level both for inband and broadband power measurements.
Do not include brackets ( [ ] ) in command script.
Time-out for the following Test Commands is 80 seconds.
Test Commands
test_bb_power
Tests TR broadband power meter for operation within specified limits.
test_trib_power
Tests TR inband power meter for operation within specified limits.
test_antib_power
Tests ANT inband power meter for operation within specified limits. The set_rfrec_port 1
command must be issued prior to test_antib_power command.
Config Commands
set_trbbpower_average
Sets number of averages used to calculate measurement.
Format: Whole number
Range: 1 to 250
set_trbbpower_ulimit [ limit W ]
Sets TR broadband power meter upper limit.
Format: Decimal limit value in W
set_trbbpower_ulen [ state 0/1 ]
Enables/Disables the upper limit check on TR broadband power meter.
Valid states are:
0 = Disabled
1 = Enabled
set_trbbpower_llimit [ limit W ]
Sets TR broadband power meter lower limit.
Format: Decimal limit value in W
set_trbbpower_llen [ state 0/1 ]
Enables/Disables the lower limit check on TR broadband power meter.
Valid states are:
0 = Disabled
1 = Enabled
set_trbbpower_zero
Zeros the broadband power meter. Not valid if power is being applied to the T/R Connector.
set_tribpower_average
Sets number of averages used to calculate measurement.
Format: Whole number
Range: 1 to 250
