Set Commands (cont)
set_scope_traceacoupling [ state 0 to 2 ]
Sets Scope Trace A coupling.
Valid states are:
0 = DC
1 = AC
2 = GND
set_scope_traceaposition [ value in divisons ]
Sets Trace A vertical position.
Valid states are +
8 divisions.
set_scope_tracebsource [ state 0 to 6 ]
Selects Trace B source
Valid states are:
0 = Off
1 = Channel1
2 = Channel2
3 = Audio
4 = Audio Filtered
5 = Demod
6 = Demod Filtered
set_scope_traceblevel
Trace B source <5 [ state 0 to 12 ]
0 = 2 mV 7 = 500 mV
1 = 5 mV 8 = 1 V
2 = 10 mV 9 = 2 V
3 = 20 mV 10 = 5 V
4 = 50 mV 11 = 10 V
5 = 100 mV 12 = 20 V
6 = 200 mV
FM (Demod/Demod filtered): [ state 0 to 6 ]
0 = 500 Hz
1 = 1 kHz
2 = 2 kHz
3 = 5 kHz
4 = 10 kHz
5 = 20 kHz
6 = 50 kHz
AM (Demod/Demod filtered): [ state 0 to 3 ]
0 = 5%
1 = 10%
2 = 20%
3 = 50%
