AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-32
Set Commands (cont)
set_scope_tracebcoupling [ state 0 to 2 ]
Sets Scope Trace B coupling.
Valid states are:
0 = DC
1 = AC
2 = GND
set_scope_tracebposition [ value in divisons ]
Sets Trace B vertical position.
Valid states are +
8 divisions.
set_scope_sweeprate [ state 0 to 18 ]
Sets Scope sweep rate.
Valid states are:
0 = 1us 7 = 200 us14 = 50 ms
1 = 2 us 8 = 500 us15 = 100 ms
2 = 5 us 9 = 1 ms16 = 200 ms
3 = 10 us 10 = 2 ms17 = 500 ms
4 = 20 us 11 = 5 ms18 = 1 s
5 = 50 us us 12 = 10 ms
6 = 100 us 13 = 20 ms
set_scope_trigmode [ state 0/1 ]
Sets Scope Trigger mode.
Valid states are:
0 = Auto
1 = Normal
set_scope_trigedge [ state 0/1 ]
Sets Scope trigger edge.
Valid states are:
0 = Rise
1 = Fall
set_scope_trigsource [ state 0 to 2 ]
Sets Scope Trigger source.
Valid states are:
0 = TRA
1 = TRB
2 = EXT
