AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-33
Set Commands (cont)
set_scope_triglevel [ level in mV / V / % / kHz / Hz ]
Sets Scope Trigger level.
Units of measurement are as follows based on selected trigger source:
CH1, CH2 or Audio trigger source:
Parameter is mV when Vertical level on 1 triggering trace is <200 mV
Parameter is V when Vertical Level on 1 triggering is >200 mV
FM Demod trigger source:
Parameters is Hz when Vertical level on 1 triggering trace is <
500 Hz
Parameter is kHz when Vertical Level on 1 triggering is >500 Hz
AM Demod trigger source:
Parameter in %
set_scope_trigfilter [ state 0 to 2 ]
Selects Scope Trigger filter.
Valid states are:
0 = No Reject
1 = Noise Reject
2 = HF Reject
set_scope_marker1_source [ state 0/1 ]
Selects Marker 1 source.
Valid states are:
0 = TRACE A
1 = TRACE B
set_scope_marker2_source [ state 0/1 ]
Selects Marker 2 source.
Valid states are:
0 = TRACE A
1 = TRACE B
set_scope_marker1enable [ state 0/1 ]
Enables/Disables Marker 1.
Valid states are:
0 = Disabled
1 = Enabled
set_scope_marker1position [ value in us ]
Sets Marker 1 position.
Format: Decimal value in us
set_scope_marker2enable [ state 0/1 ]
Enables/Disables Marker 1.
Valid states are:
0 = Disabled
1 = Enabled
set_scope_marker2position [ value in us ]
Sets Marker 2 position.
Format: Decimal value in us
