Test Set Operation
Subject to Export Control, see Cover Page for details.
3-13
VGA Monitor Output Connector
This connector is a standard VGA style, 15 way, D-type connection that allows a VGA monitor or
video projector to duplicate the Test Set’s screen display.
The VGA Monitor must be connected before the Test Set is turned on.
RS-232 Serial Connector
Standard 9 way, D-type connection.
Reserved for future development.
Parallel Printer Output Connector
The Parallel Printer Output Connector is a standard 25 way, D-type printer connection. Refer to
the section titled Print Screen Tile
for information on configuring printer setup.
