Agilent Technologies 1220 Infinity II LC

1220 Infinity II LC System User Manual 139
Detector Description
8
Match the Flow Cell to the Column
Correction factors for VWD flow cells
Table 24 Correction factors for Agilent VWD flow cells
Flow cell type Cell
volume
Part number Path length
(nominal)
Path length
(actual)
Correction
factor
Standard flow cell 14 µL Standard flow
cell, 10 mm, 14
µL, 40 bar
(G1314-60086)
10 mm 10.15 ± 0.19 mm 10/10.15
Semi-micro flow cell 5 µL Semi-micro flow
cell, 6 mm, 5 µL,
40 bar
(G1314-60083)
6 mm 6.10 ± 0.19 mm 6/6.10
Micro flow cell 2 µL Micro flow cell,
without I.D. tag, 3
mm, 2 µL, 120 bar
(G1314-60087)
3 mm 2.80 ± 0.19 mm 3/2.8
High Pressure flow cell 14 µL High pressure
flow cell, 10 mm,
14 µL, 400 bar
(G1314-60082)
10 mm 10.00 ± 0.19 mm 6/5.75
NOTE
Be aware that there are additional tolerance of gasket thickness and its compression ratio,
which are considered to be very small in comparison with the machining tolerance.
