Agilent Technologies 1220 Infinity II LC User Manual

140 1220 Infinity II LC System User Manual
8 Detector Description
Match the Flow Cell to the Column
Correction factors for DAD flow cells
Table 25 Correction factors for flow cells
Flow cell Path length
(actual)
Correction factor
Standard flow cell, 10 mm, 13 µL, 120 bar ( 12 MPa)
(G1315-60022)
9.80±0.07 mm 10/9.8
Semi-micro flow cell, 6 mm, 5 µL, 120 bar ( 12 MPa)
(G1315-60025)
5.80±0.07 mm 6/5.8
Micro flow cell, 3 mm, 2 µL, 120 bar ( 12 MPa) (G1315-60024) 3.00+0.05 mm/-0.07
mm
3/3
Semi-nano flow cell kit, 10 mm, 500 nL, 5 MPa (G1315-68724) 10.00±0.02 mm 10/10
Nano flow cell kit, 6 mm, 80 nL, 5 MPa ( G1315-68716) 6.00±0.02 mm 6/6
Standard flow cell bio-inert, 10 mm, 13 µL, 120 bar ( 12 MPa)
for MWD/DAD, includes Capillary Kit Flow Cells BIO (p/n
G5615-68755) (G5615-60022)
9.80±0.07 mm 10/9.8
NOTE
Be aware that there are additional tolerance of gasket thickness and its compression ratio,
which are considered to be very small in comparison with the machining tolerance.
