Detectors
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 178
5. Inspect the filter: chips, scratches, and/or
cracks in the light path scatter light, reduc-
ing detector sensitivity. Replace filters as
necessary.
Inspect the PMT window for damage; if
necessary, replace the PMT. See “Photomul-
tiplier tube” on page 1-201.
Figure 1-18. FPD disassembly
O-ring,
Viton
0-ring
Window, second heat shield
0-ring
Flange adapter
Flange ring
Clamp
