Released: April 2004 6850 Series Gas Chromatograph Service Procedures 83

Figure 1-24. Capping the bottom of the inlet and septum purge vent

Septum vent

Split vent

Cap the inlet column fitting

(column nut using no-hole ferrule

shown)
