Inlets and valves
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 93
Caution
When removing/attaching the inlet cryo line,
use one wrench to support the cryo line
fitting on the inlet body and one to tighten
the nut. Failure to do this could break the
fitting on the inlet.
Figure 1-31. Removing the gas lines from the inlet
Remove gas
lines
