Inlets and valves

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 99

Figure 1-35. PTV Plumbing Assemblies

PTV SMLS

gang weldment

PTV front trap

assembly

Filter and O-rings

(2) (not shown)

PTV front trap

assembly

Filter and O-rings

(2) (not shown)
