Theory of Operation
External Connectors
Multicell Transport Connector
4 SHUT DOWN (L) System has serious problem. Receiver is any module
capable to reduce safety risk.
5 Not used
6 POWER ON (H) All modules connected tosystem are switched on.
Receiver is any module relying on operation of others.
7 READY (H) System is ready for next analysis. Receiver is any
sequence controller.
8 STOP (L) Request to reach system ready state as soon as
possible (e.g. stop run, abort or finish and stop injection).
Receiver is any module performing runtime controlled
activities.
9 START REQUEST (L) Request to start injection cycle (e.g. by start key on any
module). Receiver is the autosampler.
Table 9 APG Remote Signal Distribution
Pin Signal Function
Table 10 Multicell Transport Connector
Pin Function Pin Function
1 Status 9 Limit switch (nc)
2 OUT [4] 10 Case
3 OUT [4] 11 OUT [2]
4 OUT [1] 12 OUT [2]
5 OUT [1] 13 OUT [3]
6DGND 14OUT [3]
7 DGND 15 Shield
8 Limit switch (no)
