58
Theory of Operation
External Connectors
CAN Connector
The CAN is a high speed communication interface. It is a two-wire serial bus
system supporting data communication with realtime requirements. This
CAN interface is used to connect the handheld controller of the Agilent
8453E UV-visible spectroscopy system to the spectrophotometer.
RS232C Connector
The RS232 is designed as DCE (Data Communication Equipment) with a
9 pin male SUB-D type connector. When controlling the spectrophotometer
through the RS232 interface, the connector needs to be activated and
configured by the 8-bit configuration switch next to the GPIB connector. For
switch settings, refer to Chapter 6 “Interfacing”.
Using a serial/parallel printer cable, an HP printer can be connected to the
spectrophotometer. This option is only used by the Agilent 8453E UV-visible
spectroscopy system. The 8-bit configuration switch has to be set to GPIB
communication and not to RS232 communication.
Table 11 RS232 Connector
Pin Function Pin Function
1DCD 6DSR
2RxD 7RTS
3TxD 8CTS
4DTR 9RI
5GND
