Theory of Operation
Connector Definitions
Shutter Assembly Connector
The shutter assembly is connected to the spectrophotometer processor main
(SPM) board.
Deuterium Lamp Connector
The deuterium lamp is connected to the spectrograph lamp supply (SLS)
board.
Table 16 Shutter Assembly Connector
Pin Function
1,2 Coil Filter
3,4 Coil Dark
5,6 GND
7,8 Coil Common
9,10 GND
Table 17 Deuterium Lamp Connector
Pin Function
1 Heater
2 Cathode
3 Anode
