65
Theory of Operation
Connector Definitions
Tungsten Lamp Connector
The tungsten lamp is connected to the spectrograph lamp supply (SLS)
board.
Table 18 Tungsten Lamp Connector
Pin Function
1 Vis Sense +
2 Vis Lamp +
3 Vis Lamp -
4 Vis Sense -
