112
Maintenance and Repair
Removing and Replacing Covers
Figure 26 Replacing the Sample Pan and Cuvette Holder
4 Place the plastic front cover on top of the sheet metal cover so that you are
able to connect the cable to the keyboard (SSI board).
Figure 27 Connecting the Keyboard Cable
5 Push the plastic cover down so that it locates on both sides.
6 Reconnect line power and turn on the instrument. Check that the
spectrophotometer passes its self-test, this means that the green light on the
front panel comes on and that you can do a blank measurement from your
software and the keyboard of the spectrophotometer.
