Agilent Technologies 8453 User Manual

135
Maintenance and Repair
Exchanging the Main Power Supply
Figure 49 Sliding in the Light Pipe
3 Take the snap mechanism between two fingers and press it together to get the
light pipe end into the coupler on the main power supply.
Figure 50 Attaching Light Pipe to Main Power Supply
4 Replace the middle rear foam block.
Coupler

Agilent Technologies 8453 Specifications

General

Brand	Agilent Technologies
Model	8453
Category	Laboratory Equipment
Language	English
