4 Using E9320 E-Series Power Sensors
144 N1911A/1912A P-Series Power Meters User’s Guide
The configured value is displayed below the softkey. This value
is shown in Figure 4- 108.
To indicate an off- screen trigger event, is displayed. To indicate an
off- screen trigger point, is displayed.
Trig Delay The trigger delay value is shown below the softkey.
You configure the trigger delay by pressing and entering a
numeric value in the pop- up window.
Pressing highlights to display the trace markers again.
Trace Control Press to display the Trace Control menu. Setting
the trace features are described in greater details in “Setting up the
Channel Trace” on page 62.
Your chosen trigger point is used as the reference point for the timing of all the
measurement gates.
You can also setup the trigger delay in the Trigger menu, by pressing , and
entering a value in the pop-up window.
