7 Using 8480 Series Power Sensors
178 N1911A/1912A P-Series Power Meters User’s Guide
8487A This sensor requires an APC 2.4 (f) to 50 Ω (m) N-Type adapter
(08487-60001) to connect to the POWER REF. Remove this adapter
before making measurements.
8487D Prior to calibration, an Agilent 11708A 30 dB reference attenuator
and an APC 2.4 (f) to 50 Ω (m) N-Type adapter (08487-60001) should
be connected between the power sensor and the Power Ref.
Remove this adapter before making measurements.
Sensor Connection Requirements
