11 Specifications and Characteristics
260 N1911A/1912A P-Series Power Meters User’s Guide
Measurement Speed
Pulse Characteristic
These pulse characteristics are only applicable when a P- Series wideband
sensor is used.
5
Applies to frequencies >500 MHz (See Figure 11-158).
6
Applies only when Off is selected for video bandwidth.
7
The Minimum Pulse Width is the recommended minimum pulse width viewable on the power
meter, where power measurements are meaningful and accurate, but not warranted.
8
Based on 10 samples per period.
Maximum Sample Rate and Capture Length
Measurement speed using remote
interface
≥
1500 readings per second
Rise Time and Fall Time
≤
13 ns
5,6
Minimum Pulse Width
50 ns
7
Overshoot
≤
5 %
Maximum Pulse Repetition Rate
10 MHz
8
Maximum Sampling Rate
100 Msamples/second,
continuous sampling
Maximum Capture Length
1 second
