1 Introduction
8 N1911A/1912A P-Series Power Meters User’s Guide
These keys and connectors are associated with the measurement channels
and are located on the right- hand side of the front panel.
Key Function
The arrow keys are used for navigation around the parameter entry
screens. The up and down arrows are used for selecting values
from a pop-up list, they can also be used for stepping two values, X
Scale and Y Scale. They are also used to enter text, for example,
table names.
Press this key to select a highlighted field to allow data entry, check
a checkbox and terminate entry of a popup list.
Press this key to access the zero and calibration menus.
Press this key to start and stop the acquisition of the measurement.
Press these keys to enter numeric values in the pop-up fields, for
example, the offset values. To complete the entry use the softkey.
