Connector Function
The power reference is a 1 mW (0 dBm) 50 MHz signal available
from a 50 W type-N connector. It is used for calibrating an 8480,
E-Series or N8480 Series power sensor and meter system. If the
meter is configured with Option 003, the connector is fitted to
the rear panel. The Green LED beside the connector is lit when
the calibrator is turned on.
The sensor input connectors (N1912A shown, the N1911A has
one input). If the meter is configured with Option 003, the
connectors are fitted to the rear panel.
