Available track line
patterns
Explanation Figure
A-B
Straight track line that is
laid between two points.
CMS-I-001478
A+
Straight track line that is
laid at a given angle. The
specified angle of the
track line is relative to the
north-south axis.
CMS-I-001555
Contour
Irregular track line that is
recorded while driving
between two point. The
contours will be
automatically smoothed.
CMS-I-002066
11 | Using the GPS switch
Using track lines
MG5560-EN-II | E.1 | 21.04.2020
104
