If the speed becomes irregular before the
application/spreading stops, the additional symbol
turns red and moves. The AMATRON 3 issues a
long, high signal tone. There is overlap or
underlap.
11.16
Calibrating the GPS switch
11.16.1 Correcting GPS switch
The GPS switch can be calibrated to compensate for
GPS drift. GPS drift is defined as the deviations of the
GPS signal. GPS drift results from the use of
correction sources with low precision. GPS drift can
be recognised when the vehicle symbol on the
AMATRON 3 no longer corresponds to the actual
position of the vehicle.
GPS drift can be corrected in 2 ways:
Correcting the GPS drift with a reference point
Correcting the GPS drift manually
Select "GPS switch" > .
The "Calibration" menu will be opened. The
existing reference points will be listed.
CMS-T-00004696-B.1
CMS-T-001610-C.1
11 | Using the GPS switch
Calibrating the GPS switch
MG5560-EN-II | E.1 | 21.04.2020
126
