worked area must be travelled to create a bed of the
desired size. The entered number indicates the
rhythm in which the track lines must be followed. If
e.g. a 2 is entered, every second track line must be
followed. In this way, one track line is always left out
and therefore creates beds of one working width.
1. Select "GPS switch" > > "Beds".
2. Enter the desired rhythm and confirm
CMS-I-001995
11.12.4
Defining the light bar sensitivity
When the vehicle deviates from the followed track
line, the distance of the track line deviation is shown
by arrow symbols that turn yellow consecutively
1
.
The light bar sensitivity indicates the distance by
which the vehicle can deviate from the track line
before another symbol for indicating the track line
deviation turns yellow.
CMS-I-001999
CMS-T-003420-A.1
