Eliminating faults
13
Fault Cause Remedy
Formation of stripes between the
tracks
Wrong tramlines Correct the tramlines
Calibrate the GPS drift reference
point
GPS receiver has no reception
Call up the GPS diagnosis
menu
Data available? No?
Check the connections of
antenna / external GPS.
Check if the light on the
antenna is lit. Red: Power /
Orange: GPS / Green: DGPS
Check the external GPS device.
Settings 19200 baud, 8 data
bits, no parity, 1 stop bit
Data available? Yes?
For an external device, check
the NMEA data sets: GGA,
VTG, GSA, 5Hz
Check GPS quality. Is the GPS
signal too weak? See the list of
signal requirements.
AMATRON 3 cannot be switched on
AMATRON 3 is switched on and
off too rapidly
Wait for a few seconds and
switch on again.
Pull the 9-pin connector out of
the basic equipment and plug it
in again.
The GPS switch does not switch
correctly, mainly too late.
Are the GGA, VTG and GSA
transmitted at 5 Hz?
Check the external GPS device.
The implement symbol does not
move when driving, however, it is
displayed and reacts to switching on
and off (blue, red, grey)
Are the GGA, VTG and GSA
transmitted at 5 Hz?
Check the external GPS device.
CMS-T-00004703-A.1
13 | Eliminating faults
MG5560-EN-II | E.1 | 21.04.2020
132
