NOTE
With the SBAS correction signal, a signal with
higher accuracy is available as long as the SBAS
correction signal is received.
SBAS includes the correction services EGNOS,
WAAS and MSAS. For more information on this
topic, please consult the operating manual for the
satellite receiver.
Without the correction signal, the received signal
is only corrected by a software. It can take up to 5
minutes for the corrected signal to be available.
If no corrected signal is available, the worked
area will be shown in yellow in GPS switch. When
a corrected signal is available, the worked area
will be shown in green.
Possible settings for AG-STAR with SBAS
correction signal:
SBAS GPS
Suitable for North America, Europe and Russia
12 GPS satellites
2 SBAS satellites
SBAS GPS / GLONASS
Suitable for North America, Europe and Russia
8 GPS satellites
4 GLONASS satellites
2 SBAS satellites
Possible settings for AG-STAR without SBAS
correction signal:
GPS / GLONASS 1
Suitable worldwide if SBAS is not available
10 GPS satellites
4 GLONASS satellites
GPS / GLONASS 2
Suitable worldwide if SBAS is not available
8 GPS satellites
6 GLONASS satellites
7 | AMATRON 3 configuration
GPS configuration
MG5560-EN-II | E.1 | 21.04.2020
26
