Signal Descriptions
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. A-12
ID073015 Non-Confidential
Read address channel signals for AXI Master1
Table A-14 shows the AXI read address channel signals for AXI Master1.
Table A-14 Read address channel signals for AXI Master1
Name I/O Destination Description
ARADDRM1[31:0] O AXI system devices Address.
ARBURSTM1[1:0] O Burst type:
b001
INCR incrementing burst.
b010
WRAP Wrapping burst.
ARCACHEM1[3:0] O Cache type giving additional information about cacheable characteristics.
ARIDM1[5:0] O Request ID.
ARLENM1[3:0] O The number of data transfers that can occur within each burst.
ARLOCKM1[1:0] O Lock type:
b00
Normal access.
ARPROTM1[2:0] O Protection type.
ARREADYM1 I Address ready.
ARSIZEM1[1:0] O AXI system devices Burst size:
b000
8-bit transfer.
b001
16-bit transfer.
b010
32-bit transfe.r
b011
64-bit transfer.
ARUSERM1[4:0] O [4:1] = Inner attributes
b0000
Strongly Ordered.
b0001
Device.
b0011
Normal Memory Non-Cacheable.
b0110
Write-Through.
b0111
Write-Back no Write-Allocate.
b1111
Write-Back Write-Allocate.
[0] = Shared.
ARVALIDM1 O Address valid.
