13 - Spring
14 - Bushing
15 - Shift Lever Guide
16 -
Nut
• M6 - 8 Nm
• M8 - 25 Nm
❑ Quantity: 4
17 - Gasket
❑ Between shift housing and floor
❑ Self-adhesive
❑ Adhere to shift housing
18 - Shift Housing
❑ With spring and selector bracket
❑ Spring and selector bracket cannot be removed
Audi TT 2007 ➤
Manual Transmission - Edition 10.2009
60 Rep. Gr.34 - Controls, Housing
