4.12 Bevel Box, Installing
• Tightening specifications, refer to
⇒ “1.2 Flange Shaft and Seals on Bevel Box Assembly Over‐
view”, page 220 .
Install in reverse order, paying attention to the following:
Note
Replace O-rings.
Caution
Risk of damaging sealing ring between transmission and bevel
box.
♦ Place bevel box on transmission together with right flange
shaft while turning shaft.
– Slide on bevel box completely on manual transmission, while
doing this, join splines of input shaft/bevel box centrally with
differential.
– With proper tooth position and central guiding, bevel box slips
up to stop against manual transmission.
– Tighten bevel box on transmission.
Note
Do not pull bevel box with mounting bolts against manual trans‐
mission, otherwise bevel box is canted and mounting eyelets can
break off.
– Install the bevel box bracket ⇒ page 113 .
– Install the right drive axle heat shield ⇒ page 113 .
– Install the exhaust system and cross member. Refer to ⇒ En‐
gine Mechanical; Rep. Gr. 26 ; Description and Operation .
– Install subframe. Refer to ⇒ Suspension, Wheels, Steering;
Rep. Gr. 40 ; Removal and Installation .
– Install the steering gear on the subframe. Refer to ⇒ Suspen‐
sion, Wheels, Steering; Rep. Gr. 48 ; Removal and Installa‐
tion .
– Install right drive axle. Refer to ⇒ Suspension, Wheels, Steer‐
ing; Rep. Gr. 40 ; Removal and Installation .
Audi TT 2007 ➤
Manual Transmission - Edition 10.2009
122 Rep. Gr.34 - Controls, Housing
