AudioCodes Mediant 500L - Page 720

User's Manual 720 Document #: LTRT-10532
Mediant 500L Gateway & E-SBC
 To configure Outbound Manipulation rules:
1. Open the Outbound Manipulations table (Setup menu > Signaling & Media tab >
SBC folder > Manipulation > Outbound Manipulations).
2. Click New; the following dialog box appears:
Figure 36-3: Outbound Manipulations Table- Add Dialog Box
3. Configure an Outbound Manipulation rule according to the parameters described in
the table below.
4. Click Apply.
Table 36-2: Outbound Manipulations Table Parameter Description
Parameter Description
Routing Policy
routing-policy-name
[IPOutboundManipulation_R
outingPolicyName]
Assigns a Routing Policy to the rule. The Routing Policy associates
the rule with an SRD(s). The Routing Policy also defines default LCR
settings as well as the LDAP servers if the routing rule is based on
LDAP routing (and Call Setup Rules).
If only one Routing Policy is configured in the Routing Policies table,
the Routing Policy is automatically assigned. If multiple Routing
Policies are configured, no value is assigned.
To configure Routing Policies, see ''Configuring SBC Routing Policy
Rules'' on page 705.
Note: The parameter is mandatory.
General
Index
[IPOutboundManipulation_In
dex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
manipulation-name
[IPOutboundManipulation_M
Defines a descriptive name, which is used when associating the row in
other tables.
The valid value is a string of up to 40 characters. By default, no value
