Azbil C1M - Page 184

6-22
Chapter 6. Displayed Items and Settings
Display Item Description Initial
value
User
level
Notes
C 46
Control output 1
MV scaling width
0 to 9999
The decimal point position and unit are
the same as those of the PV.
200 0 Displayed if control output 1
is set to current output by the
model No. and if control output
1 type is set to SP+MV or PV+MV.
C 47
Control output 2
range
1: 4–20 mA
2: 0–20 mA
1 0 Displayed if current output is
set as control output 2 by the
model No.
The decimal point position and
unit of scaling low and hight
limits are the same as those of
control output 1.
C 48
Control output 2
type
0: MV
1: Heating MV (for heating/cooling
control)
2: Cooling MV (for heating/cooling
control)
3: PV
4: PV (before applying ratio, bias, filter)
5: SP
6: Deviation
7: CT1 current
8: CT2 current
9: Invalid
10: SP+MV
11: PV+MV
3 0
C 49
Control output 2
scaling low limit
−1999 to +9999
The decimal point position and unit vary
depending on the setting for control
output 2 type (C48).
0 0
C 50
Control output 2
scaling high limit
1000 0
C 51
Control output 2
MV scaling width
0 to 9999
The decimal point position and unit are
the same as those of the PV.
200 0 Displayed if current output is set
as control output 2 by the model
No. and if “control output 2 type”
is set to SP+MV or PV+MV.
C 64
Communication
type
0: CPL
1: Modbus/ASCII
2: Modbus/RTU
3: PLC link
0 0 Displayed if a model with RS-485
is used.
C 65
Station address 1 to 127 (0: no communication) 0 0
C 66
Transmission speed 0: 4800 bps
1: 9600 bps
2: 19200 bps
3: 38400 bps
2 0
C 67
Data format
(data length)
0: 7 bits
1: 8 bits
1 0
C 68
Data format
(parity)
0: Even parity
1: Odd parity
2: No parity
0 0
C 69
Data format
(stop bit)
0: 1 bit
1: 2 bits
0 0
C 70
Communication
minimum response
time
1 to 250 ms 3 2
C 71
Key operation mode 0: Standard
1: Special
0 2
