Chapter 6. Displayed Items and Settings
Display Item Description Initial
value
User
level
Notes
C 72
[MODE] key function 0: Invalid
1: AUTO/MANUAL mode selection
2: RUN/READY mode selection
3: AT stop/start
4: LSP group selection
5: Release all DO latches
6: Invalid
7: User-defined bit 1
8: Invalid
1 0
C 73
Mode display setup Whether to display the settings in the
mode bank is determined by the sum of
the weights shown below.
Bit 0: AUTO/MANUAL display
No: 0. Yes: +1
Bit 1: RUN/READY display
No: 0. Yes: +2
Bit 3: AT stop/start display
No: 0. Yes: +8
Bit 4: DO latch release display
No: 0. Yes: +16
Bit 5: User-defined bit 1 ON/OFF display
No: 0. Yes: +32
Bits 6–7: Invalid
255 1
C 74
PV/SP display setup Whether to show the following items on
the operation display is determined by
the sum of the weights shown below.
Bit 0: PV
No: 0. Yes: +1
Bit 1: SP
No: 0. Yes: +2
Bit 2: LSP group No.
No: 0. Yes: +4
Bits 3–7: Invalid
15 1
C 75
MV display setup Whether to show the following items on
the operation display is determined by
the sum of the weights shown below.
Bit 0: MV
No: 0. Yes: +1
Bit 1: Heating MV / cooling MV
No: 0. Yes: +2
Bit 2: Invalid
Bit 3: AT progress
No: 0. Yes: +8
Bits 4–7: Invalid
15 1
C 76
EV display setup 0: Do not show internal event settings on
the operation display
1: Show internal event 1 settings on the
operation display
2: Show internal event 1–2 settings on
the operation display
3: Show internal event 1–3 settings on
the operation display
0 1
