Adjustment on the device
optional to assign and can be skipped. If special features like AttitudeControl or Headspeed
Governor are not installed on your device, the specific menu points for assignment will not
be accessible at all.
• The assignment for Aux [CH6] Output at Menu Point H can be skipped by pressing the
button without teaching a channel for this function in case it is not used.
• Likewise, the assignment of the channel for internal (nitro) governor can be skipped in
case it is not needed or if you don‘t want to control the governor with a separate channel, e.
g. if your transmitter does not provide enough free channels. By skipping the assignment
the internal governor function will use a different operating mode that allows to control
it via the throttle channel (set at Menu Point G) if you like. When used in an electric
model the internal governor is controlled by the throttle channel (set at Menu Point G)
in general. In this case the assignment at Menu Point I can be skipped anyway, as an
assignment will have no effect.
• Finally at Menu Point J you have to assign the channel that is used to engage the Atti-
tudeControl/rescue stabilization (only when you've installed the PROEDITION Upgrade
on your device). Again, this can be skipped if not needed or if you don‘t want to use a
separate channel (or in case you haven't enough free channels left). AttitudeControl can
still be used then. In this case the channel for the tail gyro gain(set at Menu Point F)
is used to engage AttitudeControl or you can enable it separately using the Bank Switch
feature. Please see the section about using AttitudeControl for further details.
•
Menu point Function
B Collective
C Aileron
D Elevator
E Rudder
F Tail gyro/Bank switch
G Throttle [CH5]
H Aux Output [CH6]
I Governor control (nitro only)
J AttitudeControl gain
If the Status-LED lights in red color this means either there is no valid remote control
signal available or that you did try to assign two or more channels to a function. So
check if the receiver is connected and powered properly and that you're only moving one
channel at a time when trying to do the manual function assignment.
58
