Bernina 790 PRO - Feed Dog; Adjusting the Feed Dog; Slide-On Table; Using the Slide-On Table

Sewing Preparation
39
> Pull the spool net over the thread spool. Ensure when doing so that the spool net does not slip off the
thread spool, e.g. double-insert the net over the thread spools or insert a part of the net into the thread
spool at the rear.
2.6 Feed Dog
Adjusting the Feed Dog
> To lower the feed dog, push the button «Feed Dog Up/Down».
> To raise the feed dog, push the button «Feed Dog Up/Down» again.
2.7 Slide-on Table
Using the Slide-on Table
The Slide-on Freearm Extension Table, attached to the freearm, enables the available sewing area to be
extended.
> Raise the needle.
> Raise the presser foot.
> Push the Slide-on Freearm Extension Table from the left to the right over the freearm until it engages.
> To remove the Slide-on Freearm Extension Table, press the button at the table down and pull the slide-on
table over the free arm to the left.
