MACHINE DECALS
Daily Maintenance (reorder part number 14-100472-000), Serial Number, Cautions (reorder part number
14-100146-000), Charger Connections (reorder part number 14-100954-000) and BTS/Warranty Contact
(reorder part number 14-100425-000) decals are located on the lane machine as shown in Figures
1-3and1-4. Please make sure that you understand and are familiar with the instructions on these
decals before operating or servicing this lane machine. If you need assistance or replacement decals,
please contact your authorized Distributor or the Brunswick Technical Support (BTS) in the United
States at 1-800-YES-BOWL, or internationally at 231-725-4966. For non emergency support, e-mail
techsupport@brunswickbowling.com.
(1)
(2)
(3)
MODEL NUMBER VOLTAGE
FULL LOAD AMPS
SERIAL NUMBER
FREQUENCY
HZ
PROTECTED BY THE FOLLOWING US PATENTS: 7,014,714 / 7,611,583 / 7,784,147
CAUTION !!!!! READ OPERATIONS MANUAL BEFORE USING
REMOVE POWER BEFORE SERVICING
8,122,563 OTHER PATENTS PENDING AND THE FOLLOWING CANADIAN PATENT.
R
BOWLING PRODUCTS LLC.
525 W. Laketon Ave.
Muskegon, MI 49441
REPLACE LITHIUM BATTERY ONLY WITH BRUNSWICK PART No. 14-100957-004
RECHARGE LISTED BATTERIES ONLY WITH BRUNSWICK PART No. 14-100924-000
CHARGER
MASSPOWER
OR 14-100957-002.
CA2,591,014 BRUNSWICK BOWLING PRODUCTS LLC. MUSKEGON, MI USA
14-101707-001 thru -502 100-240VAC
13
50/60
204 kg1.3 kW
ALWAYS CONNECT THE BATTERY CHARGER WHEN NOT RUNNING THE LANE MACHINE.
1
2
1. GREEN POWER LED MUST BE ON TO MONITOR BATTERIES.
2. CONNECT RED CHARGER CONNECTOR TO PORT ON LEFT HAND SIDE COVER.
USE TERRY CLOTH TOWEL.
ALWAYS INSPECT APPROACH AREAS
AND CLEAN SPILLS OR DRIPS
IMMEDIATELY.
REPLACE ANY LOOSE FOAM.
6
4
5
7
3
2
1
8
3. WIPE DRIVE WHEELS.
DAILY MAINTENANCE:
2. WIPE SQUEEGEE ASSY..
4. BLOT MID-FRAME FOAM.
5. BLOT ALL INJECTOR TIPS.
6. WIPE BOTH REAR GUIDE WHEELS.
1. WIPE ALL CLEANER SPRAY NOZZLES.
7. REMOVE BUFFER SHIELD FOAM AND
WIPER SHIELD REPLACE FOAM IF
NECESSARY.
8. WIPE REAR WHEELS.
Figure1-3.SerialNumberandDailyMaintenanceDecalLocations
(1) SERIAL # DECAL
(2) DAILY MAINTENANCE DECAL
(REORDER PART NUMBER
14-100472-000)
(3) CHARGER CONNECTION DECAL
(REORDER PART NUMBER
14-100954-000)
