96 MAX Operation & Service Manual96 Section 6: Maintenance & Service MAX Operation & Service Manual
SCHEDULED MAINTENANCE
In addition to daily maintenance, these tasks should be scheduled, depending on use. Refer to the
Preventative Maintenance Chart that accompanies the machine.
WARNING! Before performing maintenance, be sure the charger cord is
disconnected from the machine and the machine is turned off.
Scheduled Maintenance in Operating Position
(1)
(2)
(3)
Figure6-3.OperatingPosition-ScheduledMaintenance
(1) DUSTER CLUTCH ASSEMBLY
(2) WASTE RECOVERY TANK (3) CLEANER PRE-PUMP FILTER
1. Check the tension setting on duster clutch assembly. For more information, refer to the
AdjustingtheDusterClutch procedure detailed later in this section.
2. Rinse waste recovery tank with hot water.
3. Inspect all electrical connections for loose or damaged wires.
