Daily Maintenance in Operating Position
(1)
(3)
(6)
(2)
(9)
(7)
(8)
(4)
(10)
(5)
(7)
(8)
(9)
(6)
Figure6-1.OperatingPosition-DailyMaintenance
(1) WASTE RECOVERY TANK
(2) FRAME DIVISION WALL
(3) DUSTER CLOTH SUPPLY ROLL
(4) CLEANER SUPPLY TANK
(5) CONDITIONER TANK
(6) SIDE COVERS
(7) FILTERS
(8) PUMPS
(9) TOP COVERS
(10) R EAR COVER
