Handle Controls
All of the machine’s operations can be controlled using the control pad on the machine’s handle. By
putting the machine functions on the handle, we reduce stooping, kneeling and bending and allow more
healthful operation of the machine. Refer to Figure 2-6.
(1)
(2)
Figure2-6.HandleControls
(1) OPERATOR HANDLE
(2) START BUTTON
