Brunswick MAX - Error Messages that Appear During Preparation (on Approach)

MAX Operation & Service Manual 173MAX Operation & Service Manual Section7:Troubleshooting173
Error Messages that Appear During Preparation (on approach)
Error Message - Table 7-1:
The lane machine is not ready for operation.
The duster cloth is not working properly. The Duster Cloth down sensor did not activate.
NOTE:VerifyerrorsourcethroughTabletdiagnostics.
What you may observe Potential problem Action
1. Duster cloth is down and
contacting the switch
1. Broken wire or loose connection at switch
or at the electronic enclosure
2. Failed switch
1. Repair connection
2. Verify switch function using Tablet
diagnostics and replace if necessary
2. Duster cloth is down and not
contacting the switch
1. Switch has come out of adjustment
2. Duster contact roller is binding
3. Machine was on the lane during preparation
1. Re-adjust switch so it actuates when
cloth is in its full down position
2. Check duster assembly for damage;
check for loose hardware
3. Pull the machine onto the approach
and prepare to run lane
3. Duster Cloth is up and did
not lower
1. The duster cloth is routed incorrectly on the
take-up core
2. Broken wire or loose connection at motor or
at the electronic enclosure
3. Duster motor failure
1. Refer to adjustments in section 4.0
or the diagram located in the Machine
2. Repair connection
3. Verify motor function using Tablet
diagnostics and replace if necessary
