START-UP PROCEDURE
Ste p 1: Supply Power to the Machine
BATTERY OPERATION
a. Unplug the battery charger cord from the 7 pin side of the machine.
NOTE:TheMAXisdesignedtoremainonatalltimes(24/7)includingchargingtimes.Inthe
  eventthatthepowerisoff,turnonusingtheswitchonthe7pinsideofthemachinenearthe
  chargingportforthebatterychargersothechargingdatacanbelogged.TheMAXWILL
  chargeifthepowerswitchisintheoffposition.
b. With the machine in its operating position, place it on the approach in front of the foul line.
NOTE:IftheTabletdoesn’tpowerup,checkthemainswitchonthesideofthemachineor
theEmergencyStopbuttonontopoftheelectronicenclosure.Makesurethattheserialcable
assemblyispluggedintothebottomofthetablet.
c. The status window displays, “READY” in the lower, right box on the screen.
CORDED OPERATION
a. Unplug the battery cable from the Electronics Enclosure.
b. Plug in the AC/DC power supply cable into the Electronics Enclosure.
c. Plug one end of the power cord into the machine and the other end into the wall outlet. (115-volt,
50/60 HZ, 20 amp outlet or 230-volt, 50HZ, 15 amp outlet).
NOTE: IftheTabletdoesn’tpowerup,checkthemainswitchontheelectronicenclosure.Also
rotatetheemergencyshutoffswitchclockwise1/4turnandrelease.
d. Place power cord ring into the cord kill assembly.
NOTE:Thecordshouldfollowthemachinefromlanetolanetoavoidinterference.
e. The status window displays “READY” in the lower, left box on the screen.
