MAX Operation & Service Manual 9MAX Operation & Service Manual Section 1: Safety 9
GROUNDING
This Class I, Single-Phase lane cleaning/conditioning machine must be grounded while in use to protect
the operator from electric shock. The machine is provided with a three-conductor cord and a three-
contact grounding-type attachment plug to t the proper grounding-type receptacle. The GREEN/
YELLOW conductor in the cord is the grounding wire. Never connect this wire to any other terminal
than the grounding pin of the attachment plug.
A 15 Amp, 120-Volt nominal AC input grounding plug is supplied on the power cords as shown in the
Figure 1-1. Make sure that the machine is connected to an outlet having the same conguration as this
plug when your center is supplied with 120-Volt nominal AC, single phase power.
Figure 1-1
A 16 Amp, 230-Volt nominal AC input grounding Schuko type plug is supplied on the power cord
for international MAX shipments as shown in Figure 1-2. If you need to replace this plug or use an
adapter, make sure that the black wire is connected to the “line” terminal, the white wire is connected
to the “neutral” terminal and the green wire is connected to the “ground” terminal.
Figure 1-2
