MAX Operation & Service Manual 175MAX Operation & Service Manual Section7:Troubleshooting175
Error Message - Table 7-4:
The lane machine is not ready for operation.
The oil pressure is not set properly. The oil pressure is too high.
NOTE:VerifyerrorsourcethroughTabletdiagnostics.
What you may observe Potential problem Action
1. System pressure above limit
for required operating pressure
1. Broken wire or loose connection at oil
pressure control valve or at the electronic
enclosure
2. Pressure control valve failure
3. Pressure sensor failure
4. AD Converter failure on machine control
board
1. Repair connection
2. Verify oil pressure control valve function
by using Tablet diagnostics and replace if
necessary.
3. Verify sensor function using Tablet diag-
nostics and replace if necessary.
4. Call BTS
Error Messages - Table 7-5:
A communication error occurred.
NOTE:VerifyerrorsourcethroughTabletdiagnostics.
What you may observe Potential problem Action
1. This error message may occur
when the lane machine is on the
approach or at the foul line.
1. Ethernet cable not connected
2. Damaged PCB or other electrical prob-
lem inside electronics enclosure or Tablet.
1. Check connection at either end of cable
2. Call BTS
