210 MAX Operation & Service Manual210 Section9:Appendix MAX Operation & Service Manual
Spare Parts Kit Envoy Lane Machine (14-860247-000)
The Spare Parts Kit includes all items listed below. These items can also be ordered individually, with
the part number provided.
QTY. PART NUMBER
1.00 11-112134-000 TOOL - DUAL FUSE PULLER
1.00 11-616025-000 SWITCH - LEVER, SPDT, .187 QUICK CONNECT
1.00 11-616026-000 SWITCH - ROLLER LEVER, SPDT, .187, 0.1A @ 125VAC
1.00 11-616031-000 SWITCH - PIN PLUNGER, SPDT, .187 QUICK CONNECT
2.00 11-655029-001 SPIN-ON FILLER
2.00 11-655043-019 TUBE - 3/8" O.D. X 34.00" LG. POLYETHYLENE
2.00 11-655070-000 SPRAY TIP - 110°, .050 GPM, STAINLESS STEEL
2.00 11-655086-000 STRAINER - 100 MESH, 5 PSI CHECK VALVE
2.00 11-655090-000 FITTING - UNION STRAIGHT, 3/8" TUBE
1.00 14-100202-000 FITTING - GREASE, DISPERSION ROLLER
1.00 14-100378-000 FOAM - VACUUM DIFFUSER
1.00 14-100394-000 THUMB DRIVE
2.00 14-100427-000 FOAM - BUFFER SHIELD DRIP
1.00 14-100487-000 SEAL - WASTE TANK, "D" SHAPE
1.00 14-860209-000 PKG. - CLEANING MIXING VESSEL W/NO SPILL SPOUT
1.00 14-860214-000 PKG. - FUSE, 4.0A, 250V SLOW BLO, 5MM X 20MM
1.00 14-860216-000 PKG. - FUSE, 10.0A, 250V SLOW BLO, 5MM X 20MM
1.00 14-860218-000 PKG. - FUSE, 6.3A, 250V SLOW BLO, 5MM X 20MM
1.00 14-860242-000 PKG-FUSE,SLOW BLOW-UL LISTED 2.0 AMP,5 X 20MM, 250V
1.00 14-101092-000 TOOL - SQUEEGEE ADJUSTMENT
1.00 14-101263-000 AC INPUT ADAPTER - TABLET, GUI
1.00 11-672528-000 POWER RELAY - SINGLE POLE, 24V
1.00 11-672529-000 POWER RELAY - SINGLE POLE, 24V
1.00 11-696017-000 CIRCUIT BREAKER - 30 AMP
1.00 57-500114-000 POWER CORD, 2.5M, 3 COND., 220V, LANE SERVER
1.00 68-100143-000 CORD - POWER, 115V. 7.5 FT.
1.00 14-900106-000 MANUAL - MAX SPARE PARTS
1.00 14-900107-000 MANUAL - MAX OPERATION AND SERVICE
DESCRIPTION
Page 1 of 1
