212 MAX Operation & Service Manual212 Section9:Appendix MAX Operation & Service Manual
LED Indicators
Location ID Application
D23 Conditioner (Oil) Vent Valve
D29 Vacuum Motor
D31 Conditioner (Oil) Pressure Valve
D36 Buffer Lift Motor
D37 Dispersion Roller Motor
D39 Squeegee Lift Motor
D40 12 vdc Power to Motor Controller PCB
D42 Conditioner (Oil) Heater
D44 Battery Charger Solenoid
D49 Duster Cloth Motor
D57 Traction Drive Motor
D58 Duster Cloth Motor (up) Reverse
D64 Beeper
D68 Cleaner Pump
D70 Traction Drive Motor Reverse
D75 Buffer Drive Motor
D77 Traction Drive Motor Brake
D83 Conditioner (Oil) Pump
LEDApplicationsChart
