MAX Operation & Service Manual 99MAX Operation & Service Manual Section 6: Maintenance & Service 99
NOTE: Thefollowingmaintenanceitemsareexplainedindetail,laterinthissection,inthe
How to Replace, Adjust, or Lubricate Partsprocedure.
1. Clean or replace in-line cleaner, and conditioner screen lters.
2. Replace conditioner spin-on lter.
3. Lubricate squeegee lifting assembly.
4. Lubricate traction drive chain and dispersion roller chain.
5. Lubricate buffer lifting assembly.
6. Inspect buffer drive belt, check tension and adjust if needed.
7. Inspect vacuum motor assembly, clean and replace if needed. The vacuum motor is rated for
500 working hours. The motor life and performance will become less when the motor reaches
the endo of life or is contaminated by waste from an overlled recovery tank..
8. Inspect all ttings and tubing for damage and replace if needed.
9. Inspect all electrical connections and repair or replace if needed.
WARNING! Before performing maintenance, be sure the charger cord is
disconnected from the machine and the machine is off.
WARNING! Brunswick recommends using a partner whenever possible to
help with lifting or lowering the machine from the operating position. Take care
when lowering this machine into the operating position. Use proper lifting and
lowering techniques such as bending at the knees and using a back support, if
needed.
