SECTION 6 - AIR SYSTEM SERVICE
page 6-12
Front Tow Primary Manifold Stand Parts
202353S
AIR SYSTEM COMPONENTS - CONCORD AIR SYSTEM
FRONT TOW PRIMARY MANIFOLD STAND
REF DESCRIPTION
1 CLAMP #44 - STAINLESS
2 NUT, LOCK .375 UNC GR B YZD
3 BOLT .375 X 1 UNC GR5 YZD
4 BOLT .375 X 1.25 UNC GR5 YZD
5 NUT JAM .375 UNC GR2 YZD
6 CLAMP MUFFLER, 2.5 .312 ROD PLT
7 COVER PLATE HOSE CONNECT
Front Tow Primary Manifold Stand Parts
