SECTION 3 - HYDRAULIC SYSTEM SERVICE
page 3-24
SUBBAR HYDRAULICS
SDX30 1
st
SERIAL RANGE SUBBAR HYDRAULICS - up to Serial Number CKB0028188
REF DESCRIPTION
1 CYLINDER 4X12 CTD 3000PSI W/ 1 PIN
2 HOSE ASSY. HYD .375 X 190 FL
3 HOSE ASSY. HYD .375 X 189 FL
4 HOSE ASSY. HYD .375 X 168 FL
5 HOSE ASSY. HYD .375 X 100 FL
6 O-RING 1/2 OD TUBE CLASS 6
7 FITTING STL 90DEG .5MB .5MJ
8 CONNECTOR FIT STL T .5MJ .5MJ .5MB
9 BOLT .375 X 1 UNC GR5 YZD
10 WASHER .438 ID 1.0 .083 YZD
11 CLAMP HOSE FORMED 2.88X.94PNT
12 ISOLATOR HOSE CLAMP SMALL
13 HOSE HYD .375 X 188
14 HOSE HYD .25 X 188 FL
15 HOSE HYD .375 X 100 FL
16 HOSE HYD .25 X 100 FL
17 TEE 1/2-37 DEG FL-SWIVEL RUN
18 FITTING, REDUCER TUBE, REDUCER 1/2 X 3/8
19 FITTING STL .5MB .5MB
20 VALVE, CHECK BLOCK PILOT OPERATED
21 TEE .375MJ .375MJ .5MB
22 ELBOW 90DEG .5MB .375MJ
23 FASTENER TIE-WRAP .18 X 15.5LG BLK NYL
Hydraulic Components for Three-Section Machines
