Case SDX30 - SDX40 Wing Assembly

SECTION 2 - MECHANICAL SERVICE
page 2-24
SDX40 WING ASSEMBLY
REF DESCRIPTION REF DESCRIPTION
1 SPLIT PIN/SAFETY PIN ROLL PIN .312 X 2
BLKHEAVY
21 TUBE TRUSS/A MAIN FRAME RH - 40FT
(Includes bronze bushings)
2 NUT LOCK JAM 1.5-6 THIN YZD 21 TUBE TRUSS/W MAIN FRAME LH - 40FT
(Includes bronze bushings)
3 NUT LOCK 1 UNC GR B YZD NYL LK 22 CUSHION CYL RUBBER
4 NUT, LOCK .75 UNC GR C YZD 23 SPACER 33MM ID X2''ODX22MM YZD
5 NUT NYLOCK: .38 NC GR6 ZP 24 PIN WINGLIFT
6 NUT, LOCK .625 UNC GR B YZD 25 ISOLATOR HOSE CLAMP SMALL
7 BOLT .375 X 1 UNC GR5 YZD 26 BRACE WING DIAGONAL
8 BOLT .375 X 2 UNC GR5 YZD 27 BRACE WING SUPPORT
9 BOLT .625 X 2.5 UNC GR8 YZD 28 TUBE TRUSS/W WING RH W/DECALS
(Includes bronze bushings)
10 BOLT .75 X 2 UNC GR8 YZD 28 TUBE TRUSS/W WING LH
11 BOLT .75 X 2.5 UNC GR5 YZD 29 CLEVIS COUPLING CLEVIS/W BOLT ON
12 BOLT .75 X 6 UNC GR8 YZD 30 PLATE, SPACER SHIM
13 BOLT 1 X 3 UNC GR8 YZD 31 PIN, PIVOT 1.5OD X 5.630UL YZD
14 WASHER .438 ID 1.0 .083 YZD 32 TUBE, SUPPORT WING END RH
15 WASHER 1.31 ID X 2.5OD X .15 32 TUBE, SUPPORT WING END LH
16 NIPPLE, LUBE GREASE ZERK STR .25NF
TAPER
33 WASHER, SPECIAL 1.53''ID 2.5 14GA YZD
17 CLAMP HOSE FORMED 2.88X.94PNT 40 BEAM ASSY. WING FRONT RH
18 CYLINDER ASSY. HYD 5.00 X 30 IOWA 40 BEAM ASSY. WING FRONT LH
19 PIN KEEPER 41 TUBE WING RH
20 PIN, COTTER HAIRPIN 3.0MM X 49.0MM
YZD
41 TUBE WING LH
SDX40 Wing Assembly
