Case SDX30 - SDX40 Subbar Hydraulics

SECTION 3 - HYDRAULIC SYSTEM SERVICE
page 3-30
SDX40 SUBBAR HYDRAULICS
REF DESCRIPTION REF DESCRIPTION
1 FITTING STL 90DEG .5MB .5MJ 14 VALVE, PILOT CART HYD CHECK
2 ELBOW FIT STL 90DEG .5MB .375MJ 15
CYLINDER ASSY. HYD 4.5 X 12 MONARCH PNTD
3 CONNECTOR FIT STL T .5MJ .5MJ .5MB 15
CYLINDER ASSY. HYD 4.0 X 12 MONARCH PNTD
4 TEE FIT STL .375MJ .375MJ .5MB 20 HOSE ASSY. HYD .375 X 212 FL
5 FITTING, REDUCER 1/2 X 3/8 21 HOSE ASSY. HYD .375 X 197 FL
6 TEE 1/2-37 DEG FL-SWIVEL RUN 22 HOSE ASSY. HYD .375 X 210 FL
7 BOLT .375 X 1 UNC GR5 YZD 23 HOSE ASSY. HYD .375 X 147 FL
8 WASHER .438 ID 1.0 .083 YZD 24 HOSE ASSY. HYD .375 X 361 FL
9 FITTING PIO CPLR .5M-TIP .5FP 25 HOSE ASSY. HYD .25 X 149 FL
10 FITTING STL .5MB .5MB 26 HOSE ASSY. HYD .375 X 150 FL
11 CLAMP HOSE FORMED 2.88X.94PNT 27 HOSE ASSY. HYD .25 X 145 FL
12 ISOLATOR HOSE CLAMP SMALL 100 FASTENER TIE-WRAP .18 X 15.5LG BLK NYL
13 VALVE, CHECK BLOCK PILOT OPERATED
SDX40 Subbar Hydraulics
